1
replacement option found
Existing pump - Circulation
Brand
Salmson
Product name
DIE 206-16/7,5
Overall length
430 mm
Mains connection
3x400 V
Pipe Connection
DN 65 PN16
Nominal power P2
7,5 kW
Replacement pump - High Efficiency Standard Exchange sheet
Product name
Yonos GIGA2.0-D 65/1-31/7,5
Item no.
2205883
MEI
≥ 0,4
IE
5
Overall length
340 mm
Mains connection
3x400 V
Pipe Connection
DN 65 PN16
Rated Current
13,9 A
Nominal power P2
7,5 kW
Fluid temperature range
-20 - +120 °C
Comment
Fits special replacement accessories.
Product information
Yonos GIGA2.0-D 65/1-31/7,5
Yonos GIGA2.0-D 65/1-31/7,5
Item no.
: 2205883
Efficient pumping of large amounts of water for heating, air-conditioning and cooling applications in large buildings.
The Wilo-Yonos GIGA2.0-D is an electronically controlled in-line glanded pump, which is suitable for pumping large amounts of water over large delivery heads. Thanks to IE5 EC motor technology and proven pump hydraulics (MEI ≥0.4), it provides both high energy efficiency and a high level of reliability. It is very easy to use thanks to the established Green Button Technology, user-friendly menu navigation and clear colour display. Analogue and digital interfaces provide the option of integration into building automation systems.
